Pop – Putting it Back Together

Hi folks, it’s Pop here.  Janet did an excellent job explaining basically the what’s and why’s of rebuilding her little 200ci six banger.  More air, more fuel, bigger spark, bigger explosion and more power.  Carl’s Machine Shop was fantastic, and now we have to assemble the parts.  This indeed trips my trigger and I will explain the procedure much to the boredom of some of you.  But, perhaps we can convert a few into budding “gearheads”.

We’ll begin with the bare engine block which was cleaned up, magna fluxed (a process to detect cracks…it passed), over bored 60 thousands of an inch (this is the maximum and was necessary because of scoring in cylinder #4, the result of a broken ring), and new freeze plugs installed.

IMG_4275

The crankshaft went in first with .010” over bearing inserts.  This requires clearance checks using plastigauge.  Plastigauge is thin plastic thread which when compressed, spreads out and its width is then measured to determine clearance.  The top bearing shells are placed in the block, then the crankshaft, then strips of plastigauge across the bearing journals, then the bottom bearings and caps.  The bearing caps are then torqued to specs.  The caps are then removed and the width of the plastigauge measured.  I won’t further torture you with the measurements acceptable throughout the assembly procedure except to say, “everything checked out”.  (Janet: “Except to say we had to do math…math sucks.”)  The crank is then removed and turned over 180 degrees and the process repeated, assuring a straight bore and shaft.  Everything checking in specs, the bearing surfaces are lubricated, assembled and torqued to specs.  One final step, the crankshaft is then moved forward and backward to check end play.

The camshaft (which opens and closes the valves) was original and installed by Carl’s with new bearings, as this requires special tools.  (Janet: “Some of the only tools Pop apparently does NOT have in his garage. It’s just a matter of time.”)

IMG_4312

Next, the pistons with new rings (which snap into piston grooves, hold compression and control oil on the cylinder walls), three rings per piston.  Before the rings are installed in the piston grooves they must be placed in the proper cylinder bore and the gap between the ends measured.  Too close a gap and the ring will break when it expands with heat, spelling disaster.  (Janet: “Apparently I got my dramatic nature from my father.”)

IMG_4278

Each piston is fitted to numbered connecting rods then placed in the proper cylinder and attached to the crankshaft, plastigauged, lubed and torqued to specs.  With the installation of a new oil pump, the “bottom end” is now complete.



New timing chain (which goes on gears at the front end of the crankshaft and camshaft) is installed and the front cover and oil pan installed.  We’re now ready for our new and improved cylinder head.

IMG_4230

One final and most important measurement is needed, valve clearance.  We now have oversized valves and increased openings with our new 1.6 to 1 rocker arms.  Heaven forbid the valves hit the pistons at top dead center!  That would again lead to disaster.  (Janet: “Need I say more?”)

IMG_4342

With #1 piston at the top dead center, we fill the space between the block surface and the piston with clay (in our case, Playdough).  We also filled #6, then install the head gasket and head.  The head bolts are torqued, the valve train assembled and adjusted and the engine turned over 720 degrees or two revolutions of the crankshaft (one revolution of the camshaft).  With fingers crossed, we disassemble the valve train, remove the head and measure the distance from the bottom of the valve indentations to the piston surface.  Yes!  We have clearance!

IMG_4329

The top end is now reassembled and the oil pump driven by an electric drill (the bottom of the distributor shaft will do this).  Checking for oil flow from the rocker arms aaaaaaaand – success!



Finally, valve cover on and new Ford blue paint job.

IMG_4346

IMG_4357

During Janet’s next visit we’ll install our Autolite two barrel carburetor with automatic choke onto the beautiful adaptor plate on the intake manifold.  Add our new 50,000 volt ignition and big exhaust headers and we’re ready to kick some ass.



(Janet:  “Pop and I have very different ways of showing overwhelming excitement.”)








A Girl and Her Inline 6: I’m Keeping my Baby

The first week of my second trip back to Eddyville has been quite successful.  The back end is out of Mavis, which means the differential with its axle, springs, shocks, gas tank and all the various tubes and pipes that entails.  Still, everything takes longer than you think it’s going to.  Something as simple as pulling the filler neck out of the gas tank through the trunk took over an hour and we had to consult the experts.

Thank God for our new Maverick/Comet forum friends!  Inevitably someone has gone up against the same challenge and has that little tip that does the trick.  Even if the advice is to spray it down with a lubricant, have a couple beers and then bang the shit out if it.  Pop and I did cause a bit of stir when we started asking about souping up our Inline 6, which I’m happy to report we are indeed keeping (no 302 switch out for us).

img_9586

A girl and her Inline 6.

I must say though, for a bunch of macho dudes in a male dominant field, these forum guys can bitch fight with the best of them.  So, Crazy Larry from the 302/V8 crowd got into it with gregmaverick of the Inline 6 sanction over advice for Pop and me.

Crazy Larry: A car like that needs a V-8 swap. If you just want to get the car running, keep the 200 completely stock. It’s a complete waste of money trying to soup up a 200 I-6.

gregmaverick:  Sixes are way cool (posts some pics of his ‘killer 6 banger’ as Pop called it.)

Crazy Larry:  Maybe in an alternate universe. The sixes of the Ford Maverick era are no comparison to the sixes of today. They make good boat anchors, but are otherwise a big waste of time & money.

Dang Crazy Larry, you CRAZY!

gregmaverick: Larry, perhaps you have no time or no money…???

Crazy Larry: Whether I do or not is irrelevant. The fact is that spending the same amount of money on a V-8 will yield much greater performance as it would on a I-6 from the 1970s. You can argue all you want but it won’t change physics. At the end of the day, it ends up being a huge waste of time and money to hop up one of those sixes, which is something that most people who are new to these old cars do not need.

Pop and I had been interjecting with questions and such, but at this point, we sort of ‘crept away’ and let these two go at it.

gregmaverick: Gee Larry – we’re up to the challenge. “Laws of Physics”? Which ones?  I’m curious to hear your explanation in terms of Newton, thermodynamics, and bore/stroke ratio.  Perhaps you need to go back to the library and re-do your homework…?

Ooooooo-eeeeee! He did NOT!

Crazy Larry: You’re hilarious. Like I said; put the same amount of money into a V-8 as the Ford I-6 from the ’70s, and the v-8 will stomp all over it (not to mention that it will sound a heck of a lot better too).   And if Newton’s theories, or thermodynamics were on your side in this debate, there never would have been any reason to create the V-8.

gregmaverick: Well Larry, I don’t know what to tell you…except, you still haven’t answered the questions. Perhaps it’s a little too technical for you. We’ll just let it go at that.

And it goes on and on.  The forum admin tells them to ‘give it a break’ but they keep at it.  Rapture chimes in and I adore him.

Rapture: i mean wouldnt they have to upgrade their brakes, rear end, transmission, radiator, and a bunch of other small things to put in a v8? i feel that would eventually put the cost way higher for them. of course they are not going to get the same horsepower as a v8 from the inline but beefing it up for a more fun driver doesnt sound bad to me, doesnt sound like they are throwing away money necessarily. do the upgrades and enjoy, but thats just my opinionated suggestion.

It was like watching an online fight between a Trumpy and, well, everyone else, but much less maddening.  There is no lack of strong opinions in the car world.  On one of our many excursions to Harbor Freight, the ‘Bed, Bath & Beyond’ of the automotive enthusiast, we were tracked like prey by ‘Jeff’ and his V8 hard on.  When I explained our project and Mavis’s cute Inline 6 he immediately turned up his nose.  Out came the pics of his high horse power, Chevy LS crate engine and his Ford insults.  We couldn’t shake this guy, popping up around every corner to tell us what saw blade we should buy and where to get it.  After he explained that he’s been off work with a bad back, I asked him, “So this is what you do?  Hang out in Harbor Freight bugging people?”  I couldn’t help myself, by the time he was telling Pop how to hang paint tarps I was done.

This isn’t Pop’s first rodeo and the Ford Inline 6 is an incredibly strong engine, so as I said, regardless of the arguments, we’re keeping the 6.  I’m not racing this fucking thing (although you never know), but I do want a little zip.  Besides, Pop’s got his 350 V8 we can cause trouble in.  We took the Bird out the day after I got here.  Pop says, “Go tell Ma we’re going hot rodding.”  Warning, I’ve taught myself a little iMovie and I’m working on mastering the cheesy video.

As well as being a stupid good time, this little act was an exercise in differentials and how the rear axle isn’t one big tube going from one wheel to the other.  Each side is it’s own section and they can turn at different speeds.  This explains that when you ‘lay down some rubber,’ one wheel bites while the other burns it up!  How do you think you can take a tight turn and not have the outside tire skip and skid to keep up with the other?  It’s like when iceskaters do their little whip line.  The inside one basically turns in a circle while the outside gal is skating her ass off to keep up.

We made some pretty big purchases this round too.  I’m switching out the 3 leaf for 4 leaf springs.  Seeing that part of the old spring fell off as we removed it, I figured I should.  Needed new u-bolts and shackles for those and pinion seal and u-joints for the differential. We found an original front grill and fender splash guards on eBay that I grabbed and also picked up some smaller fun stuff like window handle knobs and a dome light cover.  All these little things add up so believe me I’m saving everything I can possibly save regardless of the work.  I’ve spent 3 days on the gas tank already.  I really really want to do this thing right, and as you know, I love me some physical labor, so I scraped the outside of the tank of road crap, rust protected it and painted it.  Pop and I cleaned and sealed the tank with a special 5 step process and that’s that.

img_0024

Gas tank before: Covered in tar, dirt, old undercoating and shame.

img_0115

Gas tank after: Cleaned, sealed, fast-etched (rust protected) and painted.  Proud as a peacock.

I’ve added the tank to the Before and After section of this blog…it’s just the beginning.  I love tracking this kind of stuff.  I’ve also started in with my spreadsheets for listing parts needed, bought, costs, timing, etc.  All told, we’ve figured that this little car project will cost about $10K and take 2 years.  I’ve been told it’s more realistic to double both of those numbers, but I’d like to finish the car before I turn 50!  I personally think that Pop is slow playing this whole thing to savor it, which I get cuz we’re having a blast, regardless of what Crazy Larry thinks.

Mavis, Deconstructed

Holy smokes it’s been weeks since I’ve been home and I haven’t told you about week two of the Kentucky maiden voyage!  With the Firebird finally running and out of the garage, Mavis was now the center of attention.  Yes…Mavis.  Makes me think of a wise old lady, African American, steady, proud, and cool as shit.  Cross her and she will KICK YOUR ASS.  “Sleeper” is a term for a car that looks unassuming, isn’t overly showy or flashy but can pack a punch in the power department.  Mavis is going to be a sleeper, classy and quiet, but ready to tear it up if need be.

But, we need to break Mavis down before building her back up.  The goal of the week was to get the engine and transmission removed.  To do that, you need to disconnect anything attached to them and take off anything that would impede their removal.

img_9525

Me and the old man in our workspace.  Mavis, now in the spotlight.

We started with the fender, headlights and grill.  I found that there is no such thing as “just unscrew that bolt” in these old cars.  The bolt has been bolted for 40 something years, rusted, perhaps bent and can be a bitch to get off.  I find this to be a great challenge.  We spray it down with our trusty Kroil, let it sit for a bit and then go at it.  Sometimes it’s brute strength that’s needed,  sometimes it’s finding the right tool or angle to finesse it off.

As we removed parts, Pop would explain them to me;  what they did and how they worked.  Everything was saved regardless of needing to be replaced or not.  We’d make notes of what we needed to either buy, repair or find in a junk yard.  Parts were stored in labeled containers according to what they were.  For example, headlights, their rims, bowls and wires were in a box, and all engine bolts, screws, washers and nuts were put in an old coffee can.  Wires were labeled with a sticker and note so we knew what the hell they were connected to and larger parts (hood, front fender, bumper) were propped up along the garage wall.

img_9608

The parts cart including transmission, valve cover and fly wheel.  We used to use this cart to roll the garbage to the bottom of the driveway when I was a kid. I told you, the P’s get rid of NOTHING.

Pop and I work well together because we tend to work alike.  We stay organized, work slowly and thoroughly and keep the workspace clean as we go.  It’s funny to watch him and see where I get some of my quirks.  When there were too many tools out and he’d step on one or one of us would catch a foot on the air hose and trip, we’d both seem to do a little freak out thing.  You feel a little clausto and disorganized and have to ‘tidy up’ before moving onto the next task.  It’s something about the state of your surroundings directly affecting your ability to deal.

We worked in this way for a couple days, removing every wire, tube and pipe attached to the engine.  While Pop was at breakfast with friends one morning I felt the need to get a jump on things.  Momma was in the garage with me and we had been poking around, seeing what we could clean or whatever.  I got a bit bold, decided it would be a good idea to remove the radiator and went about the business of draining it.  Momma sat in a chair, one leg crossed over the other, bouncing her foot like she does, and watched.  I undid the top hose and was surprised as to how much antifreeze came out.  Luckily I had already thought to put a bucket underneath to catch it.  Feeling confident, I proceeded to loosen the bottom hose, which started a slow drip.  Sat back with Momma to wait, but soon became impatient and decided to pull the entire hose off.  HOLY SHIT!  Neon green fluid spewed from the thing like projectile vomit!  The power of it knocked the bucket over and flooded onto the floor.  I’m screaming, “Oh my God!!!” trying to get the hose back on which only intensified the spray.  It was flowing like a firehose! I finally get to the bucket just as the last of the antifreeze empties out with a belch and it’s over as quickly as it started.  Momma’s still sitting in her chair and she says quietly, “wow.”  Clean up involved mops and the garden hose and when Pop got home I told him about my faux pas.  That’s when he showed me the petcock at the bottom of the radiator, a small valve conveniently located to drain the antifreeze.  (Yes, it’s called a petcock.  Awesome.)

Eventually it was time to remove the engine and transmission.  Pop and I cut the exhaust off all together as it was junk.  That was interesting…Pop on his back under the car with a sawsall bouncing around on the pipe, inches from his face.  We were, though, wearing safety glasses.  We supported the rear of the engine, then disconnected and removed the transmission.  Removed the bolts from the front motor mounts and lifted the engine out with the chain fall.  We are fucking pros!

img_9569

Pulley systems make you feel strong.

img_9572

Success!

img_9574

The inline 6, chained up and out.

img_9578

Mavis, now just a cold, empty shell of herself.

img_9594

We sprayed the engine compartment down with degreaser and gave her a rinse.  God how I love a power washer!

img_9606

And this is how I left her (after we pulled the wheels off).  On stands for the duration, engine extracted, ready for her make over.

Although we did get a lot of work done, I was able to spend a little fun time with the P’s.  I went with Momma to her water aerobics class a couple times.  Me and 20 plus ladies from about 60 to 80 years old moving some serious water, chatting it up.  I saw neighbors Danny and Vicki, who were so thoughtful and brought me a Life magazine that had a 1972 Maverick ad in it.

The three of us attended a surprisingly religious bluegrass concert at the Kentucky Opry House.  Apparently the word ‘gospel’ in the program title didn’t tip us off.  We went with it, had a great time and Pop kept saying, “I don’t know, I just keep smiling.”  We met Pop’s friend Jimmy there who is 89 and peppy as ever.  It’s not often you get a chance to talk with someone who starts a conversation by saying, “When I was in the Philippines during World War II.”

Pop has some stories himself and I thought I had heard them all, but during my visit things would spark a memory and he would share.  While laying under Mavis, draining transmission fluid, he told me about the old gas station he worked at as a kid.

“We moved from Rogers Park (Chicago) to Wilmette when I was 12 and I always hung around the gas station a block away.  It was called Lee’s Shell and I just showed up and started doing stuff.  The place was full service so I’d check oil, wash windows, whatever.  I wasn’t in high school yet and I don’t even know if I was paid.  Eventually I worked part-time for a little money and stayed until they sold the place when I was 17.

img_9597

Pop at 12

I was there by myself one day, I was 13 or 14.  A guy brought his car in for an oil change so I put it on the lift, drained the oil and put 5 quarts back in.  I collected his money and he left.  Turns out I hadn’t drained his oil, but mistakenly had drained his transmission fluid instead.  The guy calls later from across town with a burnt up transmission.  I was devastated…I cried…it was terrible!  Must have been a couple hundred bucks that came out of my pay to rebuild the guy’s transmission.  I remember I had to take some money out of my savings.  Very young mistake.  Lee probably would have let me get away without paying for it, but I insisted.  I was in tears.

Lee was a heavy set, rough guy.  He was nice enough to me.  Gad, the people that hung around that place.  Willy T was a Chicago Outlaw who worked there.  He was real thin, rode his Harley.  He was a full time bad dude.  Two other guys hung out there, motorcycle guys, two characters.  They had a Cushman, big motor scooter, that they had put a Harley Davidson engine in.  It was like an 80MPH Cushman!  I remember one night they were drinking and had to go to the hospital because they had crashed into each other.  They were all alcoholics.

They were all nice to me though.  They’d give me beer and let me smoke cigarettes.  I would be with Lee and on some occasions we’d go get parts or whatever, I’d tag along.  Sometimes he would go to collect bills from the housewives.  He would go into the house and I’d wait.  Sometimes he took a long time to collect the bill.”

Yes, I’m learning a lot about rebuilding cars, but I’m learning even more about Pop.

Root for the Underdog

Holy crap we found it.  Found the car that will take up all of my free time and a lot of mind space for quite possibly the entire year to come.  I can’t believe it’s happened this fast and also can’t believe that neither Pop nor I found it.  My brother Mathew did.

Momma and Pop were visiting Mat last month and I was on the phone with them all discussing the Plymouth Duster we had decided to pass up.  It felt like I needed to nail down the type of car I really wanted and intensify the search based on that.  When Pop asked which car I was really feeling serious about, the one that really got me excited about the project, I had to admit that I truly dug the Ford Maverick.

The Maverick is a smaller car, has a beautiful little shape to it and was one of the very first cars that caught my eye when I started looking.  Now, I say I had to ‘admit’ that the Maverick was the one because the Maverick has gotten shit over the years for not being, I don’t know, cool enough.  People write that it is a cheap car, a poser, a pseudo muscle car, etc.  Five years after the Mustang came out, which was based on the Falcon’s platform, Ford introduced the Maverick, which also shared the Falcon’s engine and running gear.  It was not only more affordable than the Mustang, but was also meant to be Ford’s competitor to the crazy popular Volkswagen Beetle and other foreign cars that were getting bought up.  At the time, the 6 cylinder 200 and 250 engines had more than enough power for a subcompact ‘economy’ car and they marketed the thing as ‘The Simple Machine’.  Mavericks made before 1973 didn’t even have a glove compartment as that was apparently an added expense for an unnecessary luxury.

d629904661b969efc604f38741a55fa0

Ford Maverick, “The Simple Machine.”  I’ve read articles where it’s been referred to as “The Simple Machine for the Simpleton,” which I think is just rude!

The Grabber trim package was introduced later in 1970 and with its 302 V8, exterior graphics and spoiler, was definitely vying for the attention of the muscle car crowd.  But still, there are those that won’t give this little underdog any respect…and that’s another reason why I love it.  I’ve always rooted for the underdog.

So when Mat drove home from visiting with the P’s that night and caught a glimpse of what looked like a Maverick on the side of the road for sale, he couldn’t believe it.  Not an hour after telling him that I wanted a Mav, he found a Mav.  He texted, “Totally hooked a u-turn on Rt. 14…I was like, holy shit, a Maverick!”  He pointed his brights on her and sent me what would be the first peek at my baby.

img_9152-2

The next morning the P’s took it for a test-drive in the rain.  Momma Face Timed with me which was hilarious.  God I wish I had video.  Pop’s driving, it’s loud, raining hard and Momma is about as steady with the camera as an old drunk.  As she discovers things (she’s as excited as we are) she’s yelling over the noise, “Jan!  The windshield wipers work!  Ooooh!  Look at this, there’s a shelf where the glovebox would be!!  The interior is decent.  Can you see this??  We couldn’t figure out the seatbelts!! Can you hear me?  Where do I have this thing pointed?!!!”  This is when I tell her about the option to turn the camera lens around rather than the camera itself.  “Oh, I had no idea!  Woody!!  Be careful!  How far are you planning to go?  Can you see?!?  I can’t believe this rain!!”  I love that woman.

The 1972 Maverick has a 200 cu. in. engine with an inline 6.  This means that it is a 6 cylinder and they line up in a row, rather than 3 on both sides of the engine tilting outward (hence the V in a V6 or V8.)  It’s got a manual transmission with ‘3 on the tree’ which means the gear shift is on the steering column.  It’s currently silver, but based on the VIN it came out of the factory a bright yellow. Pop and I negotiated with the seller and I ended up buying it for $3,500.

I am so unbelievably excited!  Although I feel like a mother whose newborn has been whisked away before having a chance to hold it.  I look at the pics every day and I’ve had a couple video ‘visits’.  Here’s a general overview from Pop:

The Mav is currently parked in Mat’s garage in Cary, IL.  The plan is to drive Mike’s truck out there mid October, trailer the car and haul her down to KY where I’ll spend a few weeks.  I’m really really looking forward to seeing my Mat.  He is one of the kindest people I know and a great brother, father and friend.  He’s empathetic and emotional, loving and caring.  Mat has followed in Pop’s footsteps and drives a truck for a living.  He works his fucking ass off and still seems to find time to help anyone in need.  But I’ll tell you, in recent years, Mat has been given the shit end of the stick more often than not.  He has been tested past the point where many would have given up.  He is a single parent, trying to raise an incredibly troubled son while his other son lives miles away.

So to Mathew I say…You are a fighter.  You continue to get up every morning and face the long work days and weekend overtime as well as the ongoing, physically and mentally exhausting, heartbreakingly sad battle at home.  I am very proud of you.  Thank you for finding this little car for me.  I truly believe it was a sign that it was you who found it.  You are now a permanent part of this journey with me (especially because you’ve already committed to helping us with brakes.)

I promise you little brother, the underdog will have its day.  I love you and I’ll see you soon.

11013105_10206124616252288_3000803325827205835_n

One of my favorite pics.  Mathew with Hudson…always taking care.
